Shop MAXLITE

Digital Wall Switch

  • Mfr # CN-RDMSB-V2
  • Zoro # G216388579

product price:
$
55.89
/ea

Key Features

Overall Height
1.93 in
Installation Location
Fixture
Manufacturer Warranty
5 yr
Sensor Operation
0 to 10V Dimming, Photocell, Occupancy
Coverage Type
Large Motion, Small Motion
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
CN-RDMSB-V2
Zoro #
G216388579
UPC #
767627061622
Country of Origin
China
Item
Motion Sensor
Installation Location
Fixture
Manufacturer Warranty
5 yr
Sensor Operation
0 to 10V Dimming, Photocell, Occupancy
Coverage Type
Large Motion, Small Motion
Communication Method
Hard Wired
Maximum Coverage Area
5,000 sq ft
Minimum Operating Temperature
-30 Degrees F
Load Rating @ 120V AC
12 mA max
Lighting Technology
LED
Includes
Locking screw,silcone cover
Standards
cULus Listed E511069, California Title 20 Compliant, FCC Part 15 Subpart B Class A
Color
Bronze
Maximum Operating Temperature
130 Degrees F
Sensing Technology
Passive Infrared (PIR)
Wire Color
Bronze
Operating Voltage
12-20V DC

Dimensions

Overall Height
1.93 in
Maximum Mounting Height
40 ft
Overall Diameter
2.48 in
Minimum Mounting Height
10 ft
Overall Width
2.48 in

Description

Motion Sensor, Sensing Technology Passive Infrared (PIR), Operating Voltage 12-20V DC, Maximum Coverage Area 5,000 sq ft, Maximum Mounting Height 40 ft, Load Rating @ 120V AC 12 mA max, Communication Method Hard Wired, Color Bronze, Includes Locking screw,silcone cover, Sensor Operation 0 to 10V Dimming, Photocell, Occupancy, Lighting Technology LED, Installation Location Fixture, Standards cULus Listed E511069, California Title 20 Compliant, FCC Part 15 Subpart B Class A
