Digital Wall Switch

  • Mfr # CNA-RDMSW
  • Zoro # G716388598
product price:
$
46.55
/ea

Key Features

Minimum Mounting Height
10 ft
Sensor Operation
0 to 10V Dimming, Photocell, Occupancy
Maximum Operating Temperature
131 Degrees F
Sensing Technology
Passive Infrared (PIR)
Installation Location
Fixture
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
CNA-RDMSW
Zoro #
G716388598
UPC #
767627033780
Country of Origin
China

Dimensions

Minimum Mounting Height
10 ft
Overall Height
2.91 in
Maximum Mounting Height
40 ft
Overall Diameter
2.59 in
Overall Width
2.59 in

Details

Item
Motion Sensor
Sensor Operation
0 to 10V Dimming, Photocell, Occupancy
Maximum Operating Temperature
131 Degrees F
Sensing Technology
Passive Infrared (PIR)
Installation Location
Fixture
Includes
Locking screw,silcone cover
Lighting Technology
LED
Load Rating @ 120V AC
12 mA max
Minimum Operating Temperature
-30 Degrees F
Standards
IP66, cULus Listed E511069, California Title 20 Compliant, FCC Part 15 Subpart B Class A
Manufacturer Warranty
5 yrs
Color
White
Coverage Angle
90 Degrees
Maximum Coverage Area
5,000 sq ft
Communication Method
Hard Wired
Wire Color
White

Description

Motion Sensor, Sensing Technology Passive Infrared (PIR), Operating Voltage 12-20V DC, Maximum Coverage Area 5,000 sq ft, Maximum Mounting Height 40 ft, Load Rating @ 120V AC 12 mA max, Communication Method Hard Wired, Color White, Includes Locking screw,silcone cover, Sensor Operation 0 to 10V Dimming, Photocell, Occupancy, Lighting Technology LED, Installation Location Fixture, Standards IP66, cULus Listed E511069, California Title 20 Compliant, FCC Part 15 Subpart B Class A
