Butt Hinge, Steel, Flush Mounting, 1 7/16 in Leaf W x 3 1/2 in Leaf H, Oil Rubbed Bronze
- Mfr # 55430
- Zoro # G6668599
product price:Â
$
22.69
/ea
Key Features
Corners
Radius 1/4 in
Door Leaf Height
3 1/2 in
Door Leaf Thickness
0.13 in
Door Leaf Width
3 1/2 in
Holes per Leaf
3
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- 55430
- Zoro #
- G6668599
- UPC #
- -
- Country of Origin
- Taiwan, Province of China
- Corners
- Radius 1/4 in
- Finish
- Oil Rubbed Bronze
- Holes per Leaf
- 3
- Load Capacity
- 150 lb
- Material
- Steel
- Mounting
- Flush
- Range of Motion
- 270 Degrees
- Features
- For Flush Door/Frame/Wall Applications, For Low Frequency Doors, Where Doors are Beveled Edge on Hinge Side, Specify T4314 or T4714
- Item
- Butt Hinge
- Color
- Dark Gray
- Standards
- ANSI/BHMA 156.7
- Pin Type
- Barrel
- Pin Material
- Steel
- Bearing Type
- Plain
- Holes
- With
- Ligature Resistant
- No
- Hardware
- Yes
- Hand Orientation
- Non-Handed
- Includes Hardware
- Hardware Included
- Mounting Style
- Full Mortise
- Corner Type
- Square
- ANSI/BHMA Finish
- Dark Oxidized Satin Bronze, Oil Rubbed
- Range of Motion - Maximum
- 270 Degrees
- Number of Holes per Leaf
- 3
Description
Butt Hinge, Steel, Oil Rubbed Bronze Finish, 150 lb Load Capacity, 3 Holes per Leaf, No Ligature Resistant, 270 Degrees Range of Motion, 3 1/2 in Door Leaf Height, 3 1/2 in Frame Leaf Height, 3 1/2 in Door Leaf Width, 1 7/16 in Frame Leaf Width, 0.13 in Door Leaf Thickness, 0.13 in Frame Leaf Thickness, Plain Bearing Type, Radius 1/4 in Corners, Yes Hardware
