Shop MEGGER

Clamp On Earth Resistance Tster, 1500 Ohm

  • Mfr # DET14C

  • Zoro # G3695237

product price:
$
2,315.99
/ea
Free Shipping & Returns

Key Features

Ground Resistance Range
0.050 to 1500 ohm
Resolution
0.01 to 10 Ohms
Operating Frequency
1,390 Hz
Data Logging
256 Records
Jaw Capacity
1.5 in (39mm)
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
DET14C
Zoro #
G3695237
UPC #
013088353821
Country of Origin
United Kingdom

Dimensions

Manufacturers Warranty Length
1 yr
Battery Size
AA

Details

Item
Clamp On Earth Resistance Tester
Ground Resistance Range
0.050 to 1500 ohm
Resolution
0.01 to 10 Ohms
Operating Frequency
1,390 Hz
Data Logging
256 Records
Jaw Capacity
1.5 in (39mm)
Battery Type
(4) 1.5V AA
Counts
4 Digit + 6 Digit With Backlight
Includes
Calibration Check 1001-498, Carrying Case, Carrying Strap (Wrist Loop) 1001-716
Current Measurement Range
0.5 mA to 35.0 A
Display
Digital LCD
Resistance Accuracy
High Range +/-35%, Low Range +/-1.5%
Safety Rating
IP30, EN 61010-2-032 & CATIV 600V Polution Degree 2
Auto Power Off
Yes
Communication Protocol
Bluetooth
Number of Records Stored
256
Leakage Current Range
0.5 mA to 35 A
Calibration Certificate
Available Separately
Minimum Operating Temperature
-4 Degrees F
Maximum Operating Temperature
122 Degrees F
Dustproof
Yes
Bluetooth Compatible
Yes
Includes Batteries
Batteries Included
Leakage Current Measurement - Maximum
35 A
Data Output Type
No Output
CAT Safety Rating
CAT IV 600V
Calibration Certificate Included
No Certification Included
Maximum Ground Resistance Measurement
1,500 ohm
Test Voltage
25 V, 50 V
Power Source
Battery
Test Current
3 A
Features
Balance Elements of a Ground to Mitigate Noise, Balance Ground Circuits, Elliptical Clamp Shape Improves Access to Earth Cables and Straps upto 50 mm, Low Maintenance Flat Jaw Interface, Measure Continuity of Ground Circuits in Headends and Hubs
Leakage Current Measurement - Minimum
0.5 mA
Tester Type
Clamp-On Ground Resistance Tester
IP Rating
IP30
Resistance Testing Functions
AC Current, Ground Loop Resistance
Display Screen Type
LCD with Backlight
Data Logger
Yes
Power Source - TS Only
Battery
Power Source - old
Battery

Description

Clamp On Earth Resistance Tester, Bluetooth Compatible No, CAT Safety Rating CAT IV 600V, Calibration Certificate Available Separately, Data Logger Yes, Dustproof Yes, IP Rating IP30, Jaw Capacity 1.5 in (39mm), Leakage Current Range 0.5 mA to 35 A, Maximum Ground Resistance Measurement 1,500 ohm, Number of Records Stored 256, Resistance Accuracy High Range +/-35 Percent, Low Range +/-1.5 Percent, Test Current 3 A, Test Voltage 25 V, 50 V, Communication Protocol Bluetooth, Battery Size AA
