This item is Discontinued.

Meltric Watertight Pin & Sleeve Receptacle, 50 A, 480V AC, 2 Pole, Screw Terminals Wire Connection Type 31-34242-K04-375-4X

Watertight Pin & Sleeve Receptacle, 50 A, 480V AC, 2 Pole, Screw Terminals Wire Connection Type (Discontinued)

  • Mfr # 31-34242-K04-375-4X
  • Zoro # G601756129
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
31-34242-K04-375-4X
Zoro #
G601756129
UPC #
784474041904
Country of Origin
United States

Dimensions

Use With Installation Accessory Size
3
Wire Size
14 AWG to 4 AWG
Wire Strip Length
Phase: 9/16 in (14 mm)

Details

Item
Watertight Pin & Sleeve Receptacle
Current Rating
50 A
Voltage Rating
480V AC
Number of Poles
2
Number of Wires
3
IP Rating
IP66, IP67
NEMA Enclosure Rating
4X
Wire Connection Type
Screw Terminals
Housing Color
Blue
Cap Type
Flip-Up Cap
Standards
cCSAus, 155873, C22.2 No. 182.1-13, E79796, UL 1682
Resistance Properties
Impact Resistant
Body Material
Polyester
Operating Temp. Range
-40C to 60C
Number of Aux. Outputs
NO AUX
Impact Rating
IK08
Color Code
Red
Contact Configuration
2P+G
Keying Position
24
Short Circuit Current Rating
100 KA - MAKE & WITHSTAND
Tightening Torque
Phase: 15 IN-LBS / 1.7 N-M
Hz
60 Hz
Wire Temperature Rating
60 Degrees C
Load Break Amp Rating_Abnormal Overload
75A

Description

DR50 RECEPTACLE POLY BLUE SIZE 3 TYPE 4X 2P+G 50A 480 VAC 60 Hz NO AUX MUSHROOM PAWL TYPE 4X WATERTIGHTNESS
