  11. Watertight Pin & Sleeve Inlet, 20 A, 250V DC, 2 Pole, Screw Terminals Wire Connection Type Blue

This item is Discontinued.

Meltric Watertight Pin & Sleeve Inlet, 20 A, 250V DC, 2 Pole, Screw Terminals Wire Connection Type Blue 33-18209-4X

Watertight Pin & Sleeve Inlet, 20 A, 250V DC, 2 Pole, Screw Terminals Wire Connection Type Blue (Discontinued)

  • Mfr # 33-18209-4X
  • Zoro # G301757167
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
33-18209-4X
Zoro #
G301757167
UPC #
784474669818
Country of Origin
United States

Dimensions

Use With Installation Accessory Size
2
Wire Strip Length
Phase: 3/4 in (19 mm)
Wire Size
14 AWG to 8 AWG

Details

Item
Watertight Pin & Sleeve Inlet
Current Rating
20 A
Voltage Rating
250V DC
Number of Poles
2
Number of Wires
3
IP Rating
IP66, IP67
NEMA Enclosure Rating
4X
Wire Connection Type
Screw Terminals
Housing Color
Blue
Cap Type
No Cap or Cover
Standards
cCSAus, 155873, C22.2 No. 182.1-13, E79796, UL 1682
Resistance Properties
Corrosion Resistant
Body Material
Polyester
Use With
Mating Box MB3
Tightening Torque
Phase: 15 IN-LBS / 1.7 N-M
Operating Temp. Range
-40C to 60C
Impact Rating
IK08
Keying Position
20
Wire Temperature Rating
60 Degrees C
Contact Configuration
2P+G
Color Code
Blue
Number of Notch Positions
24
Load Break Amp Rating_Abnormal Overload
30A

Description

DSDC1 INLET POLY BLUE SIZE 2 TYPE 4X 2P+G 20A 250 VDC TYPE 4X WATERTIGHTNESS
