AccessoryPin, Polycarbonate, 1Pole, 3.6mmW
- Mfr # FSPIN1
- Zoro # G0904371
product price:Â
$
0.98
/ea
Sold in multiples of 20 for $19.60
Key Features
Wire Type
Solid/Stranded CU
Available accessories
For multi-pole panel mounting, simply snap in pins for rigid fit. Cap plugs provide the ability to maintain touch safety on unused openings. Circuit identification markers simply snap into blocks to ID circuits. End anchors provide rigid end stops
Compact modularity
Single or multiple pole configurations in the most compact footprint. Allows users to build smaller or higher density panels
Multiple wire ratings
Provide users more versatility by offering capability of using multiple conductors in #2 and 2/0 openings
AC & DC ratings
FSPDB1, 2, and 3 have been evaluated for use at 1500V (AC or DC) provided they are installed on DIN-rails only and with proper barriers and spacing between poles of opposite polarity
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- FSPIN1
- Zoro #
- G0904371
- UPC #
- -
- Country of Origin
- Mexico
- Item
- Accessory Pin
- Wire Type
- Solid/Stranded CU
- Available accessories
- For multi-pole panel mounting, simply snap in pins for rigid fit. Cap plugs provide the ability to maintain touch safety on unused openings. Circuit identification markers simply snap into blocks to ID circuits. End anchors provide rigid end stops
- Compact modularity
- Single or multiple pole configurations in the most compact footprint. Allows users to build smaller or higher density panels
- Multiple wire ratings
- Provide users more versatility by offering capability of using multiple conductors in #2 and 2/0 openings
- AC & DC ratings
- FSPDB1, 2, and 3 have been evaluated for use at 1500V (AC or DC) provided they are installed on DIN-rails only and with proper barriers and spacing between poles of opposite polarity
- Captive termination screws
- Unique channel design ensures captive metric wire termination screws. Screws can never be lost
- Min Storage Temp
- -25 °C
- Max Operating Temp
- 80 °C
- Max Storage Temp
- 80 °C
- Wire Insulation Rating
- 60/75C
- Flammability Rating
- 94 V-0
- Short Circuit Rating Standalone
- 10 kA
- Snap on DIN-rail mounting
- Sizes 1 to 4 feature integral DIN rail adaptors allowing for quick and easy installations on 35mm DIN rail yielding lower installed costs
- Finger-safe protection
- Fully insulated block ensures touch safe isolation of live parts. Recessed termination screws and wire openings provide IP20 grade protection and qualify as €œfingersafe€ per IEC 529
- Short Description
- FSPDB UL1059 AL V 0A 0 in/0 out /
- APPLICATIONS
- Splicing cables; Splitting primary power into a variety of secondary circuits; Providing a fixed junction tap-off point
- Short Circuit Rating (Standalone)
- 10 kA
- Item Description (ERP)
- FSPDB ACCESSORY PIN TO FORM MU
- APPROVALS & STANDARDS
- UL Recognized Component Guide XCFR2, File E73571; CSA Certified: Class 6228, File 69363; IEC-947-7-1, 529, 68-2-6, CE Marked
- Material
- Polycarbonate
- Number of Poles
- 1
- Compatible with Series
- FSPDB Finger-Safe Power Distribution Blocks
Description
Accessory Pin, Compatible with Series FSPDB Finger-Safe Power Distribution Blocks, Material Polycarbonate, Mounting Type Direct Mount, Number of Poles 1, Overall Depth 52.1 mm, Overall Length Not Applicable, Overall Width 3.6 mm, Thickness 0.08 in
