  5. Open Fuse Block, 401 to 600A Amp Range, 300V AC/DC Volt Rating, 1 Poles, Box Lug
Mersen Open Fuse Block, 401 to 600A Amp Range, 300V AC/DC Volt Rating, 1 Poles, Box Lug 36031T - main

Open Fuse Block, 401 to 600A Amp Range, 300V AC/DC Volt Rating, 1 Poles, Box Lug

  • Mfr # 36031T

  • Zoro # G2342444

product price:  $178.75
/ea
Free Shipping & Returns

Key Features

UL Class
T
Series
6TFB
Voltage Rating
300V AC/DC
Connector Type
Box Lug
Mounting Style
Bolt-Down
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
36031T
Zoro #
G2342444
UPC #
-
Country of Origin
Mexico

Dimensions

Width
3 in
Length
5-3/4 in
Height
3.09 in
For Fuse Size
3-1/16 in L x 1-1/4 in dia, 3-1/16 in L x 1-5/8 in dia
Mounting Hole Dia.
1/4 in
Overall Width
3 in
Wire Size - Maximum
600 kcmil
Overall Height
3.09 in
Overall Length
5.75 in

Details

Item
Open Fuse Block
UL Class
T
Series
6TFB
Number of Poles
1
Amp Range
401 to 600A
Voltage Rating
300V AC/DC
Connector Type
Box Lug
Mounting Style
Bolt-Down
Visual Indication
Non-Indicating
Fuse Block Style
Non-Rejection
Spring Reinforced Clip
Yes
Fuse Block Design
Open
Body Material
Polycarbonate
Standards
CSA Certified, UL Listed
Features
High Conductivity Copper Alloy Fuse Clips
Fuse Type
Industrial
For Fuse Series
A3T
Fits Fuse Type
Class T
Wire Range
2 AWG to 600 MCM
Short Circuit Current (KA)
200 kA
Frequency Range (Hz)
50/60 Hz
Max. Operating Temp.
80 deg C
Fuse Installation Method
Clip-in
APPROVALS & STANDARDS
All fuse blocks meet the requirements of UL 4248; UL listed, guide IZLT, File E52283; UL recognized component guide IZLT2, file E52283; CSA certified class 6225, File 32169
Fits Fuse Block Style
Non-Rejection
Current - Maximum
600 A
AC Voltage Rating
300 V AC
DC Voltage Rating
300 V DC
Current - Minimum
401 A

Description

Fuse Block, Fits Fuse Type Class T, Fuse UL Class T, 401 to 600 A, Number of Poles 1, 300V AC/DC, For Fuse Size 3 1/16 in L x 1 1/4 in dia, 3 1/16 in L x 1 5/8 in dia, Compatible Fuse Series A3T, JJN, JLLN, TJN, Series 6TFB, Non-Indicating, Non-Rejection, Fuse Block Design Open, Wire Range 600 MCM, Mounting Style Bolt-Down, Body Material Glass Filled Polycarbonate, Connector Type Box Lug, Height 3.09 in, Width 3 in, Length 5.75 in, Spring Reinforced Clip Yes
