  11. UL Class Fuse, RK1 Class, Time-Delay, 50A, 250V AC, Indicating
Mersen UL Class Fuse, RK1 Class, Time-Delay, 50A, 250V AC, Indicating A2D50R - main

UL Class Fuse, RK1 Class, Time-Delay, 50A, 250V AC, Indicating

  • Mfr # A2D50R

  • Zoro # G1075767

product price: $21.03
/ea

Key Features

Class
RK1
Series
A2D-R
Speed
Time-Delay
AC Voltage Rating
250V AC
DC Voltage Rating
250V DC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
A2D50R
Zoro #
G1075767
UPC #
00782001990930
Country of Origin
United States

Dimensions

Length
3 in.
Diameter
13/16 in.
Overall Diameter
13/16 in
Overall Length
3 in

Details

Class
RK1
Series
A2D-R
Speed
Time-Delay
Amps
50A
AC Voltage Rating
250V AC
DC Voltage Rating
250V DC
Visual Indication
Indicating
Interrupt Rating
100kA at 250V DC, 200kA at 250V AC
Body Style
Cylindrical
Body Material
Polyester
Equivalent Brand and Series
Bussmann LPN-RK-SPI, Littelfuse LLNRK-ID, Mersen A2D-R
Equivalent Series
A2D-R, LLNRK-ID, LPN-RK-SPI
Fits Fuse Block Style
Rejection
Compatible Fuse Block Series
2HKRFB
Item
UL Class Fuse
Rated voltage DC UL
250 V
Standards
CSA C22.2 No. 248.12, DC UL 248, UL 248-12 File E2137
Weight
0.14 lb
Mounting
Clip
Element
Dual
AC Max I.R./Breaking Capacity: I1
200 kA
Connection/Terminal Material
Tin-Plated Copper
Frequency
50/60 Hz
Fuse Holder Code
K
Body/Insulating Material
PolyTube
APPROVALS & STANDARDS
UL listed to standard 248-12 File E2137; DC listed to UL standard 248; CSA certified to standard C22.2 No. 248.12
Connection/Terminal Type
Ferrule
Connection Type
Ferrule
Short Description
Fuse Amp-Trap 2000® 250V 50A Time-Delay Class RK1 A2D Series Smart-Spot
Functionally Equal To
Bussmann LPN-RK-SPI, Littelfuse LLNRK-ID
Green Environmental Attribute
RoHS 2011/65/EU Compliant
Indication System Type
SmartSpot®
Interrupt Rating - DC
100 kA
Interrupt Rating - AC
200 kA
Current
50 A

Description

Fuse, 50 A, 250 V AC, 250 V DC, Class RK1, A2D-R Series, Indicating, Time-Delay, Body Style Cylindrical, Fits Fuse Block Style Rejection, Interrupt Rating 100kA at 250V DC, 200kA at 250V AC, Fuse Size 3 in L x 13/16 in dia, Length 3 in, Diameter 13/16 in, Equivalent Brand and Series Bussmann LPN-RK-SPI, Littelfuse LLNRK-ID, Mersen A2D-R, Equivalent Series A2D-R, LLNRK-ID, LPN-RK-SPI, Compatible Fuse Block Series 2HKRFB, Body Material Polyester, Dual Element
