Butterfly Valve, Spring Return, 1-1/2 In.
- Mfr # MBSAO A 112
- Zoro # G0365793
product price:Â
$
1,029.99
/ea
Free Shipping & Returns
Key Features
Body Material
Bronze
Standards
WW-V-1967
Max. Water Pressure
175 psi
Air Inlet Pressure
80 psi
Seat Material
Viton
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- MBSAO A 112
- Zoro #
- G0365793
- UPC #
- 697988605459
- Country of Origin
- China
- Item
- Pneumatically Actuated Butterfly Valve
- Body Material
- Bronze
- Standards
- WW-V-1967
- Max. Water Pressure
- 175 psi
- Air Inlet Pressure
- 80 psi
- Seat Material
- Viton
- Action
- Spring Return
- Seal Material
- FKM
- Product Type
- Pneumatically Actuated Butterfly Valve
- Disc Material
- Stainless Steel
- Fail Safe Position
- Fail Closed
- Actuator Operation
- Air to Spring
- Coefficient of Volume (Cv)
- 112
- Maximum Pressure - Steam
- Not Rated
- Actuator Features
- Auxiliary Limit Switch
- Operating Temperature - Maximum
- 250 Degrees F
- 3-A Standard Compliance
- Not Rated
- Valve Deactivated State
- Normally Closed (NC)
- Maximum Pressure - Operating
- 175 psi
- Liner Material
- FKM
- Vacuum Service Rating
- Not Rated
- Actuator Air Pressure - Maximum
- 80 psi
- Operating Temperature - Minimum
- 0 Degrees F
- For Media
- Corrosive Chemicals, Salt Water
Description
Pneumatically Actuated Butterfly Valve, Action Spring Return, Body Material Bronze, Pipe Size 1 1/2 in, Max. Water Pressure 175 psi, Seat Material Viton, Standards WW-V-1967, Air Inlet Pressure 80 psi, Product Type Pneumatically Actuated Butterfly Valve
