  11. Horizontal Optical Comparator, 14" Size
Mitutoyo Horizontal Optical Comparator, 14" Size 172-868-11A-QM - main

Horizontal Optical Comparator, 14" Size

  • Mfr # 172-868-11A-QM

  • Zoro # G0986227

product price: $19,704.99
/ea
Item requires special delivery charges. A $230.00 per item surcharge will be applied.

Key Features

Image Type
Erect Image
Protractor Screen
14 in
Illumination
24V, 150 W Halogen
Magnification
10x
Table Size (In.)
17-11/16 x 5-11/16
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
172-868-11A-QM
Zoro #
G0986227
UPC #
603908577034
Country of Origin
Japan

Dimensions

Table Size (In.)
17-11/16 x 5-11/16
Size
14 in
Screen Size
14 in
Table Size
17 11/16 in x 5 11/16 in

Details

Item
Optical Comparator
Image Type
Erect Image
Protractor Screen
14 in
Illumination
24V, 150 W Halogen
Magnification
10x
Projector Series
Mitutoyo PH-3515F
Reading
Linear Scale
Focusing Travel
6 in
Accuracy
+/-0.1% Or Less (Contour), +/-0.15% Or Less (Surface)
Capacity (Lb.) Max.
100
Power Supply
Corded
Resolution
0.0001 in
Includes
Projection Lens Set, Work Stage, Power Cord, Halogen Bulb, Tube Fuse, Grounding Wire, Hex Wrench, Vinyl Cover
Table Travel
X Axis=10 in, Y Axis=6 in
Measuring Unit
Linear Scale
X-Axis Table Travel
10 in
Contour Illumination
24V, 150W Halogen Bulb
Surface Illumination
24V, 150W Halogen Bulb
Y-Axis Vertical Focus Travel
6 in
Effective Table Working Area
17 11/16 in x 5 11/16 in
Optical System Orientation
Horizontal
Magnification - Included Lens
10X
Adjustable Brightness
Yes
Digital Readout Interface Included
QM-Data 200

Description

Optical Comparator, Resolution 0.0001 in, Accuracy +/-0.1 Percent Or Less (Contour), +/-0.15 Percent Or Less (Surface), Contour Illumination 24V, 150W Halogen Bulb, Effective Table Working Area 17 11/16 in x 5 11/16 in, Image Type Erect Image, Magnification - Included Lens 10X, Measuring Unit Linear Scale, Optical System Orientation Horizontal, Projector Series Mitutoyo PH-3515F, Screen Size 14 in, Surface Illumination 24V, 150W Halogen Bulb, Table Size 17 11/16 in x 5 11/16 in
