Mitutoyo Screw Pitch Gage, 4 to 42/0.4 to 7mm 188-151 - main

Screw Pitch Gage, 4 to 42/0.4 to 7mm

  • Mfr # 188-151

  • Zoro # G3019317

product price: $64.55
/ea

Key Features

Leaves
Narrow Design With Flattened Teeth
Range of Pitches per Inch
0.4 to 7mm TPI
Number of Leaves
51
Locking Device
Yes
Construction
Steel Case With Folding Leaves
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
188-151
Zoro #
G3019317
UPC #
603908057543
Country of Origin
Japan

Details

Item
Thread Pitch Gauge Set
Leaves
Narrow Design With Flattened Teeth
Range of Pitches per Inch
0.4 to 7mm TPI
Number of Leaves
51
Locking Device
Yes
Construction
Steel Case With Folding Leaves
Type
Unified and Metric
Range of Pitches per Millimeter
0.4 to 7
Thread Angle (Deg.)
60
Minimum TPI
0.4 mm
Thread Angle
60 Degrees
Included Thread Pitch - mm
0.4 mm, 0.5 mm, 0.7 mm, 0.75 mm, 0.8 mm, 0.9 mm, 1 mm, 1.25 mm, 1.5 mm, 1.75 mm, 2 mm, 2.5 mm, 3 mm, 3.5 mm, 4 mm, 4.5 mm, 5 mm, 5.5 mm, 6 mm, 6.5 mm, 7 mm
Gauge Material
Steel
Maximum TPI
7 mm
Included Threads per Inch
4 TPI, 4 1/2 TPI, 5 TPI, 5 1/2 TPI, 6 TPI, 7 TPI, 8 TPI, 9 TPI, 10 TPI, 11 TPI, 11 1/2 TPI, 12 TPI, 13 TPI, 14 TPI, 15 TPI, 16 TPI, 18 TPI, 20 TPI, 22 TPI, 24 TPI, 26 TPI, 27 TPI, 28 TPI, 30 TPI, 32 TPI, 34 TPI, 36 TPI, 38 TPI, 40 TPI, 42 TPI
Thread Type
Metric
Maximum Thread Pitch - mm
7 mm
Minimum Thread Pitch - mm
0.4 mm

Description

The Mitutoyo 188-151 Screw Pitch Gage is a high-quality thread pitch gauge set that features 51 leaves and a folding case. It is the perfect tool for accurately measuring screw threads in metric and unified sizes. The set has narrow leaves with flattened teeth to ensure accurate measurements on even the smallest pitches. This unit comes with a steel case that can be folded up when not in use, which makes it easy to store. With 0.4 mm to 7 mm TPI range of pitches per inch or millimeter, you will find this versatile thread pitch gauge set useful for various applications. Whether you are an automotive technician, electrician or engineer, you definitely want to own the Mitutoyo 188-151 Screw Pitch Gage Set.
