Shop MOLEX

0.084 Series Mlx Header 4Ckt With Peg

  • Mfr # 367570063

  • Zoro # G405979267

product price:
$
1.15
/ea
Sold in multiples of 80 for $92.00

Key Features

Number of Rows
1
Standards
CSA Certified; UL E29179
Material
Polyester
Application
Board-to-Board, Power, Wire-to-Board
Features
Glow-Wire Capable
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
367570063
Zoro #
G405979267
UPC #
-
Country of Origin
India

Dimensions

PCB Thickness - Recommended
1.60mm
PC Tail Length
4.30mm

Details

Number of Rows
1
Standards
CSA Certified; UL E29179
Material
Polyester
Application
Board-to-Board, Power, Wire-to-Board
Features
Glow-Wire Capable
Color
White
Current Rating
12 A; 20 A
Max. Temp.
105°C
Contact Finish
Tin Plated
Max. Voltage
600V
Terminal Type
Through Hole
Flammability Rating
UL 94V-2
Number of Contacts
4
Terminal Finish
Tin Plated
Hole Center to Center
6.35 mm
Polarized to PCB
Yes
Temperature Range - Operating
-55° to +105°C
Series
36757
Polarized to Mating Part
Yes
Glow-Wire Capable
Yes
Material - Metal
Phosphor Bronze
Material - Plating Termination
Tin
Component Type
PCB Header
Shrouded
Fully
UL
E29179
Orientation
Vertical
Breakaway
No
Current - Maximum per Contact
12.0A, 20.0A
Stackable
No
Product Name
MLX
PCB Locator
Yes
First Mate / Last Break
No
CSA
LR19980
Material - Resin
Polyester
Durability (mating cycles max)
50
PCB Retention
Yes
Material - Plating Mating
Tin
Circuits (Loaded)
4
Pitch - Mating Interface
6.35mm
Keying to Mating Part
Yes
Lock to Mating Part
Yes
