  11. 1.25 W/B SGL R/A Rec Assy 3Ckt G Plt ETP
Molex 1.25 W/B SGL R/A Rec Assy 3Ckt G Plt ETP 502386-0371 - main

1.25 W/B SGL R/A Rec Assy 3Ckt G Plt ETP

  • Mfr # 502386-0371

  • Zoro # G2763850

product price: $0.54
/ea
Sold in multiples of 1200 for $648.00

Key Features

Plating min - Mating
0.102µm
Number of Rows
1
Orientation
Right Angle
Circuits (Loaded)
3
Keying to Mating Part
Yes
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
502386-0371
Zoro #
G2763850
UPC #
-
Country of Origin
Malaysia

Dimensions

Mated Height
5.55mm

Details

Plating min - Mating
0.102µm
Number of Rows
1
Orientation
Right Angle
Circuits (Loaded)
3
Keying to Mating Part
Yes
Color - Resin
Natural
Plating min - Termination
0.102µm
Current - Maximum per Contact
1.0A
Material - Metal
Copper Alloy
Temperature Range - Operating
-40° to +105°C
Material - Plating Termination
Gold
Termination Interface: Style
Surface Mount
Material - Plating Mating
Gold
UL
E29179
Material - Resin
High Temperature Thermoplastic
Circuits (maximum)
3
Durability (mating cycles max)
30
Pitch - Termination Interface
1.25mm
Polarized to Mating Part
Yes
Voltage - Maximum
50V AC (RMS)/DC
Lock to Mating Part
Yes
Guide to Mating Part
Yes
Pitch - Mating Interface
1.25mm
PCB Retention
Yes
