  11. 16B SEST M ins Scrw 16P 16A 500V n32
This item is Discontinued.
Molex 16B SEST M ins Scrw 16P 16A 500V n32 936010279

16B SEST M ins Scrw 16P 16A 500V n32 (Discontinued)

  • Mfr # 936010279
  • Zoro # G2764788
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
936010279
Zoro #
G2764788
UPC #
-
Country of Origin
China

Dimensions

Component Size
32B «77X62»
Stripping Length
7.00mm
Wire Size (AWG)
14-20

Details

CSA
256883
Material - Plating
Silver
Insert Color
Grey
Insert Series
S-EST
UL
E249674
Material - Contact
Copper Alloy
Polarized to Mating Part
Yes
Current - Maximum per Contact
16.0A
Durability (mating cycles max)
700
Voltage - Maximum
500V
Component Type
Inserts - Screw Terminal
Tightening Test Torque
0.50 Nm
Gender
Female
Product Name
GWconnect
Temperature Range - Operating
-40° to +125°C
Material - Insert
Polycarbonate
Series
93601
Number of Rows
2
Poles
32
Standard
CSA C22.2 NO. 182.3, EN 60664-1, EN 61984, UL 1977
Wire Protection
Yes
Lock to Mating Part
Yes
