Contact our U.S. based teamSpecifications
Product Information
MFR #
19017-0009
Zoro #
G7921782
UPC #
-
Country of Origin
United States
Dimensions
Wire Size AWG
18, 20, 22
Wire Insulation Diameter
3.40mm max.
Tab Width
4.75mm
Tab Thickness
0.81mm
Details
Material - Metal
Brass
Orientation
Straight
Voltage - Maximum
600V
Material - Resin
PVC
Flammability
94V-0
UL
E79133
Material - Plating Mating
Tin
Color - Resin
Red
Gender
Female
Barrel Type
Closed
CSA
LR18689
Insulation
PVC
Material - Plating Termination
Tin
Temperature Range - Operating
-50° to +105°C
