Product Information
MFR #
192730008
Zoro #
G705899708
UPC #
-
Country of Origin
United States
Dimensions
Tab Width
7.87mm
Tab Thickness
0.41mm
Wire Size (AWG)
14, 16
Details
Insulation
None
Connection Type
Female
Wire Range
16 to 14 AWG
Insulation Type
Non-Insulated
Seam
Closed
Max. Temp.
105 Degrees C
Connection Material
Brass
Standards
CSA Listed; UL E79133
Orientation
Straight
Type
Quick Disconnect
Material - Plating Mating
Tin
Glow-Wire Capable
No
Material - Plating Termination
Tin
Temperature Range - Operating
-55° to +105°C
Series
19273
Voltage - Maximum
Per Wire Specification
CSA
LR18689
UL
E79133
Product Name
Krimptite,Quixon
Lock to Mating Part
None
Insulated
No
