5.08Mm Euro Plug Vert Me Fwe Blk 2Ckt
Mfr # 395373002
Zoro # G205919012
product price:Â
$
0.92
/ea
Sold in multiples of 89 for $81.88
Key Features
Circuits (Loaded)
2
Wire Size mm²
0.13-3.31
Voltage - Maximum
300V
Pitch - Mating Interface
5.08mm
Current - Maximum per Contact
18.0A
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 395373002
- Zoro #
- G205919012
- UPC #
- -
- Country of Origin
- China
Dimensions
- Wire Size mm²
- 0.13-3.31
- Wire Size AWG
- 12, 14, 16, 18, 20, 22, 24, 26
Details
- Circuits (Loaded)
- 2
- Voltage - Maximum
- 300V
- Pitch - Mating Interface
- 5.08mm
- Current - Maximum per Contact
- 18.0A
- Orientation
- Vertical
- Entry Angle
- Horizontal
- Temperature Range - Operating
- -40° to +105°C
- Lock to Mating Part
- Yes
- Number of Rows
- 1
- Polarized to Mating Part
- Yes
- UL
- E48521
- Panel Mount
- No
- Stackable
- No
- Pitch - Termination Interface
- 5.08mm
