  11. 6B SEST F ins Scrw 6P 16A 500V
This item is Discontinued.
Molex 6B SEST F ins Scrw 6P 16A 500V 936010209

6B SEST F ins Scrw 6P 16A 500V (Discontinued)

  • Mfr # 936010209
  • Zoro # G2755170
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
936010209
Zoro #
G2755170
UPC #
-
Country of Origin
China

Dimensions

Component Size
6B «44x27»
Wire Size (AWG)
14-20
Stripping Length
7.00mm

Details

Material - Contact
Copper Alloy
Durability (mating cycles max)
700
Temperature Range - Operating
-40° to +125°C
Current - Maximum per Contact
16.0A
Product Name
GWconnect
Poles
6
Flammability
UL 94V-0
UL
E249674
Insert Color
Grey
Insert Series
S-EST
Voltage - Maximum
500V
Component Type
Inserts - Screw Terminal
Standard
CSA C22.2 NO. 182.3, EN 60664-1, EN 61984, UL 1977
Tightening Test Torque
0.50 Nm
Material - Plating
Silver
Polarized to Mating Part
Yes
Number of Rows
2
CSA
256883
Material - Insert
Polycarbonate
Wire Protection
Yes
Series
93601
Gender
Female
Lock to Mating Part
Yes
