Board Connector, 10 Contact(S), 1 Row(S), Male, Right Angle, Solder Terminal

  • Mfr # 395126010

  • Zoro # G305892505

product price:  $2.29
/ea
Sold in multiples of 45 for $103.05

Key Features

Max. Temp.
105°C
Max. Voltage
300V
Series
39512
Standards
UL E48521
Type
Euro Block
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
395126010
Zoro #
G305892505
UPC #
-
Country of Origin
China

Dimensions

PCB Thickness - Recommended
2.50mm
PC Tail Length
3.50mm

Details

Max. Temp.
105°C
Max. Voltage
300V
Series
39512
Standards
UL E48521
Type
Euro Block
Hole Center to Center
3.81 mm
Number of Contacts
10
Number of Rows
1
Current Rating
8 A
Orientation
Horizontal
Shrouded
Fully
Pitch - Mating Interface
3.81mm
Component Type
PCB Header
Temperature Range - Operating
-40° to +105°C
Current - Maximum per Contact
8.0A
Product Name
ESE,Eurostyle Pluggable
Circuits (Loaded)
10
Lock to Mating Part
None
Stackable
No
UL
E48521
Polarized to Mating Part
Yes
