  6. Board Connector, 11 Contact(S), 1 Row(S), Male, Straight, 0.156 Inch Pitch, Solder Terminal, Latch,
Molex Board Connector, 11 Contact(S), 1 Row(S), Male, Straight, 0.156 Inch Pitch, Solder Terminal, Latch, 26614110 - main

Board Connector, 11 Contact(S), 1 Row(S), Male, Straight, 0.156 Inch Pitch, Solder Terminal, Latch,

  • Mfr # 26614110

  • Zoro # G005892539

product price:  $2.89
/ea
Sold in multiples of 30 for $86.70

Key Features

Max. Temp.
235°C
Max. Voltage
250V
Application
Power, Wire-to-Board
Series
41791
Standards
CSA Certified; UL E29179
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
26614110
Zoro #
G005892539
UPC #
-
Country of Origin
India

Dimensions

Contact Plating Thickness
0.508 µm
PCB Thickness - Recommended
1.60mm
PC Tail Length
3.56mm

Details

Max. Temp.
235°C
Max. Voltage
250V
Application
Power, Wire-to-Board
Series
41791
Standards
CSA Certified; UL E29179
Color
Natural
Material
Polyester
Hole Center to Center
3.96 mm
Terminal Type
Through Hole
Flammability Rating
UL 94V-0
Number of Rows
1
Number of Contacts
11
Terminal Finish
Matte Tin Plated
Contact Finish
Gold Plated
Current Rating
7 A
Product Name
KK 396
Circuits (Loaded)
11
PCB Locator
No
Glow-Wire Capable
No
Shrouded
Partial
Flammability
94V-0
Material - Metal
Brass
Voltage - Maximum
600V AC (RMS)/DC
Material - Plating Termination
Matte Tin
Plating min - Mating
0.508µm
CSA
LR19980
Breakaway
No
Polarized to Mating Part
Yes
Lock to Mating Part
Yes
Max-Duration
5
Material - Resin
Polyester
Temperature Range - Operating
See Product Specification
UL
E29179
Material - Plating Mating
Gold
Durability (mating cycles max)
25
Current - Maximum per Contact
7.0A
Orientation
Vertical
Stackable
Yes
Polarized to PCB
No
Component Type
PCB Header
PCB Retention
None
Max-Temp
235
Pitch - Mating Interface
3.96mm

Description

Board Connector, 11 Contact(S), 1 Row(S), Male, Straight, 0.156 Inch Pitch, Solder Terminal, Latch, Receptacle
