  11. Board Connector, 13 Contact(S), 1 Row(S), Male, Right Angle, 0.098 Inch Pitch, Solder Terminal,
Molex Board Connector, 13 Contact(S), 1 Row(S), Male, Right Angle, 0.098 Inch Pitch, Solder Terminal, 22057135 - main

Board Connector, 13 Contact(S), 1 Row(S), Male, Right Angle, 0.098 Inch Pitch, Solder Terminal,

  • Mfr # 22057135

  • Zoro # G905891939

product price: $0.44
/ea
Sold in multiples of 250 for $110.00

Key Features

Max. Temp.
105°C
Max. Voltage
250V
Application
Signal, Wire-to-Board
Series
5268
Standards
CSA Certified; UL E29179
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
22057135
Zoro #
G905891939
UPC #
-
Country of Origin
Korea, Republic of

Dimensions

Contact Plating Thickness
4.064 µm
PC Tail Length
3.50mm
PCB Thickness - Recommended
1.60mm

Details

Max. Temp.
105°C
Max. Voltage
250V
Application
Signal, Wire-to-Board
Series
5268
Standards
CSA Certified; UL E29179
Color
Natural
Material
Nylon
Hole Center to Center
2.5 mm
Terminal Type
Through Hole
Current Rating
3 A
Flammability Rating
UL 94V-0
Contact Finish
Tin Plated
Terminal Finish
Tin Plated
Number of Rows
1
Number of Contacts
13
CSA
LR19980
Stackable
No
Orientation
Right Angle
Temperature Range - Operating
-55° to +105°C
Product Name
Mini-SPOX
Shrouded
Fully
Durability (mating cycles max)
30
PCB Retention
None
Pitch - Mating Interface
2.50mm
PCB Locator
No
Lock to Mating Part
Yes
Breakaway
No
Guide to Mating Part
No
Current - Maximum per Contact
3.0A
Plating min - Mating
4.064µm
Polarized to Mating Part
Yes
Material - Plating Mating
Tin
Flammability
94V-0
Material - Plating Termination
Tin
Circuits (Loaded)
13
UL
E29179
Keying to Mating Part
None
Glow-Wire Capable
No
Polarized to PCB
No
First Mate / Last Break
No
Component Type
PCB Header
Material - Resin
Nylon

Description

Board Connector, 13 Contact(S), 1 Row(S), Male, Right Angle, 0.098 Inch Pitch, Solder Terminal, Locking, Natural Insulator, Receptacle
