  6. Board Connector, 17 Contact(S), 1 Row(S), Male, Straight, 0.1 Inch Pitch, Solder Terminal, Latch,
Molex Board Connector, 17 Contact(S), 1 Row(S), Male, Straight, 0.1 Inch Pitch, Solder Terminal, Latch, 705450051 - main

Board Connector, 17 Contact(S), 1 Row(S), Male, Straight, 0.1 Inch Pitch, Solder Terminal, Latch,

  • Mfr # 705450051

  • Zoro # G405891774

product price:  $5.15
/ea
Sold in multiples of 15 for $77.25

Key Features

Max. Voltage
250V
Max. Temp.
105°C
Application
Signal, Wire-to-Board
Series
70545
Standards
CSA Certified
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
705450051
Zoro #
G405891774
UPC #
-
Country of Origin
United States

Dimensions

Contact Plating Thickness
0.381 µm
PCB Thickness - Recommended
1.60mm
PC Tail Length
3.30mm

Details

Max. Voltage
250V
Max. Temp.
105°C
Application
Signal, Wire-to-Board
Series
70545
Standards
CSA Certified
Color
Black
Hole Center to Center
2.54 mm
Features
Surface Mount Compatible
Material
High Temperature Thermoplastic
Terminal Type
Through Hole
Number of Rows
1
Terminal Finish
Tin Plated
Number of Contacts
17
Flammability Rating
UL 94V-0
Current Rating
3 A
Contact Finish
Gold Plated
Durability (mating cycles max)
50
Material - Resin
High Temperature Thermoplastic
Lock to Mating Part
Yes
Pitch - Mating Interface
2.54mm
Flammability
94V-0
PCB Locator
Yes
Component Type
PCB Header
CSA
LR19980
UL
E29179
PCB Retention
Yes
Polarized to Mating Part
Yes
Shrouded
Fully
Current - Maximum per Contact
3.0A
Circuits (Loaded)
17
Breakaway
No
Plating min - Mating
0.381µm
Stackable
No
Material - Metal
Brass, Phosphor Bronze
Temperature Range - Operating
-40° to +105°C
Glow-Wire Capable
No
Material - Plating Mating
Gold
Material - Plating Termination
Tin
Orientation
Vertical
Product Name
SL

Description

Board Connector, 17 Contact(S), 1 Row(S), Male, Straight, 0.1 Inch Pitch, Solder Terminal, Latch, Black Insulator, Receptacle
