  11. Board Connector, 18 Contact(S), 2 Row(S), Male, Straight, 0.079 Inch Pitch, Surface Mount Terminal,
This item is Discontinued.
Molex Board Connector, 18 Contact(S), 2 Row(S), Male, Straight, 0.079 Inch Pitch, Surface Mount Terminal, 878321821

Board Connector, 18 Contact(S), 2 Row(S), Male, Straight, 0.079 Inch Pitch, Surface Mount Terminal, (Discontinued)

  • Mfr # 878321821
  • Zoro # G305891249
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
878321821
Zoro #
G305891249
UPC #
-
Country of Origin
Slovenia

Dimensions

Contact Plating Thickness
0.762 µm

Details

Max. Voltage
125V
Max. Temp.
260°C
Application
Signal, Wire-to-Board
Series
87832
Standards
CSA Certified; UL E29179
Color
Black
Features
Surface Mount Compatible
Hole Center to Center
2 mm
Material
Nylon
Terminal Type
Surface Mount
Flammability Rating
UL 94V-0
Contact Finish
Gold Plated
Current Rating
2 A
Number of Rows
2
Terminal Finish
Tin Plated
Number of Contacts
18
Stackable
No
Circuits (Loaded)
18
Max-Duration
10
Current - Maximum per Contact
2.0A
CSA
LR19980
Temperature Range - Operating
-55° to +105°C
Guide to Mating Part
No
Glow-Wire Capable
No
Material - Plating Mating
Gold
Product Name
Milli-Grid
First Mate / Last Break
No
Material - Resin
Nylon
Durability (mating cycles max)
100
Plating min - Mating
0.762µm
Keying to Mating Part
Yes
Material - Plating Termination
Tin
Orientation
Vertical
Polarized to PCB
No
Pitch - Mating Interface
2.00mm
Max-Temp
260
Component Type
PCB Header
Flammability
94V-0
Lock to Mating Part
Yes
PCB Locator
Yes
Shrouded
Fully
Material - Metal
Phosphor Bronze
Max-Cycle
1
UL
E29179
PCB Retention
None
Breakaway
No

Description

Board Connector, 18 Contact(S), 2 Row(S), Male, Straight, 0.079 Inch Pitch, Surface Mount Terminal, Locking, Black Insulator, Receptacle
