  11. Board Connector, 20 Contact(S), 2 Row(S), Male, Straight, 0.1 Inch Pitch, Surface Mount Terminal,
Molex Board Connector, 20 Contact(S), 2 Row(S), Male, Straight, 0.1 Inch Pitch, Surface Mount Terminal, 15913200 - main

Board Connector, 20 Contact(S), 2 Row(S), Male, Straight, 0.1 Inch Pitch, Surface Mount Terminal,

  • Mfr # 15913200

  • Zoro # G405891910

product price: $2.29
/ea
Sold in multiples of 2500 for $5,725.00

Key Features

Max. Temp.
260°C
Max. Voltage
250V
Application
Board-to-Board, Signal, Wire-to-Board
Series
71308
Standards
CSA Certified; UL E29179
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
15913200
Zoro #
G405891910
UPC #
-
Country of Origin
Mexico

Dimensions

Contact Plating Thickness
0.813 µm

Details

Max. Temp.
260°C
Max. Voltage
250V
Application
Board-to-Board, Signal, Wire-to-Board
Series
71308
Standards
CSA Certified; UL E29179
Hole Center to Center
2.54 mm
Color
Black
Features
Breakaway
Terminal Type
Surface Mount
Material
High Temperature Thermoplastic
Number of Contacts
20
Current Rating
3 A
Terminal Finish
Tin Plated
Number of Rows
2
Contact Finish
Gold Plated
Flammability Rating
UL 94V-0
Product Name
C-Grid
Material - Metal
Phosphor Bronze
Pitch - Mating Interface
2.54mm
Glow-Wire Capable
No
Temperature Range - Operating
-40° to +120°C
Material - Plating Mating
Gold
Orientation
Vertical
PCB Retention
None
PCB Locator
No
Durability (mating cycles max)
50
Current - Maximum per Contact
3.0A
Shrouded
No
Component Type
PCB Header
Breakaway
Yes
CSA
LR19980
Material - Resin
High Temperature Thermoplastic
Material - Plating Termination
Tin
Max-Duration
30
Max-Cycle
3
Stackable
Yes
Plating min - Mating
0.813µm
Max-Temp
260
Circuits (Loaded)
20
Flammability
94V-0
Lock to Mating Part
None
Polarized to PCB
No
Polarized to Mating Part
No
UL
E29179

Description

Board Connector, 20 Contact(S), 2 Row(S), Male, Straight, 0.1 Inch Pitch, Surface Mount Terminal, Black Insulator, Receptacle
