  11. Board Connector, 25 Contact(S), 1 Row(S), Female, Straight, 0.1 Inch Pitch, Crimp Terminal, Black

This item is Discontinued.

Molex Board Connector, 25 Contact(S), 1 Row(S), Female, Straight, 0.1 Inch Pitch, Crimp Terminal, Black 50579225

Board Connector, 25 Contact(S), 1 Row(S), Female, Straight, 0.1 Inch Pitch, Crimp Terminal, Black (Discontinued)

  • Mfr # 50579225
  • Zoro # G605892625
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
50579225
Zoro #
G605892625
UPC #
-
Country of Origin
United States

Details

Max. Temp.
105°C
Application
Signal, Wire-to-Board
Series
70066
Standards
CSA Certified; UL E29179
Hole Center to Center
2.54 mm
Connector Type
Receptacle
Material
Polyester Alloy
Color
Black
Number of Contacts
25
Number of Rows
1
Flammability Rating
UL 94V-0
Pitch - Mating Interface
2.54mm
Keying to Mating Part
Yes
Glow-Wire Capable
No
Circuits (maximum)
25
Material - Resin
Polyester Alloy
Temperature Range - Operating
-40° to +105°C
Stackable
No
UL
E29179
Product Name
SL
CSA
LR19980
Flammability
94V-0
Lock to Mating Part
No

Description

Board Connector, 25 Contact(S), 1 Row(S), Female, Straight, 0.1 Inch Pitch, Crimp Terminal, Black Insulator, Plug
