  11. Board Connector, 3 Contact(S), 1 Row(S), Male, Right Angle, 0.1 Inch Pitch, Solder Terminal,
Molex Board Connector, 3 Contact(S), 1 Row(S), Male, Right Angle, 0.1 Inch Pitch, Solder Terminal, 22288034 - main

Board Connector, 3 Contact(S), 1 Row(S), Male, Right Angle, 0.1 Inch Pitch, Solder Terminal,

  • Mfr # 22288034

  • Zoro # G205891981

product price: $0.25
/ea
Sold in multiples of 368 for $92.00

Key Features

Max. Voltage
500V
Max. Temp.
235°C
Application
Board-to-Board, Signal, Wire-to-Board
Series
42377
Standards
CSA Certified; UL E29179
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
22288034
Zoro #
G205891981
UPC #
-
Country of Origin
India

Dimensions

Contact Plating Thickness
0.762 µm
PC Tail Length
3.05mm
PCB Thickness - Recommended
1.60mm

Details

Max. Voltage
500V
Max. Temp.
235°C
Application
Board-to-Board, Signal, Wire-to-Board
Series
42377
Standards
CSA Certified; UL E29179
Material
High Temperature Thermoplastic
Hole Center to Center
2.54 mm
Terminal Type
Through Hole
Color
Black
Features
Breakaway; Surface Mount Compatible
Terminal Finish
Tin Plated
Flammability Rating
UL 94V-0
Contact Finish
Gold Plated
Number of Rows
1
Number of Contacts
3
Current Rating
4 A
UL
E29179
Lock to Mating Part
None
Material - Resin
High Temperature Thermoplastic
CSA
LR19980
Product Name
KK 254
Breakaway
Yes
Shrouded
Partial
Material - Plating Termination
Tin
Component Type
PCB Header
Pitch - Mating Interface
2.54mm
Glow-Wire Capable
No
Circuits (Loaded)
3
Durability (mating cycles max)
100
Max-Duration
5
Stackable
No
Material - Plating Mating
Gold
Current - Maximum per Contact
4.0A
PCB Locator
No
Polarized to PCB
No
Material - Metal
Brass
PCB Retention
None
Max-Temp
235
Plating min - Mating
0.762µm
Polarized to Mating Part
Yes
Temperature Range - Operating
See Product Specification
Flammability
94V-0
Orientation
Right Angle

Description

Board Connector, 3 Contact(S), 1 Row(S), Male, Right Angle, 0.1 Inch Pitch, Solder Terminal, Receptacle
