  11. Board Connector, 3 Contact(S), 1 Row(S), Male, Straight, 0.156 Inch Pitch, Solder Terminal,
Molex Board Connector, 3 Contact(S), 1 Row(S), Male, Straight, 0.156 Inch Pitch, Solder Terminal, 416710002 - main

Board Connector, 3 Contact(S), 1 Row(S), Male, Straight, 0.156 Inch Pitch, Solder Terminal,

  • Mfr # 416710002

  • Zoro # G905892486

product price: $0.59
/ea
Sold in multiples of 150 for $88.50

Key Features

Max. Voltage
250V
Max. Temp.
235°C
Application
Power, Wire-to-Board
Series
41671
Standards
CSA Certified; UL E29179
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
416710002
Zoro #
G905892486
UPC #
-
Country of Origin
Mexico

Dimensions

Contact Plating Thickness
0.381 µm
PC Tail Length
4.37mm
PCB Thickness - Recommended
1.60mm

Details

Max. Voltage
250V
Max. Temp.
235°C
Application
Power, Wire-to-Board
Series
41671
Standards
CSA Certified; UL E29179
Features
Breakaway
Color
Black
Terminal Type
Through Hole
Material
Polyester
Hole Center to Center
3.96 mm
Number of Rows
1
Contact Finish
Gold Plated
Flammability Rating
UL 94V-0
Current Rating
7 A
Number of Contacts
3
CSA
LR19980
Plating min - Mating
0.381µm
Current - Maximum per Contact
7.0A
Durability (mating cycles max)
50
UL
E29179
Polarized to Mating Part
Yes
Temperature Range - Operating
See Product Specification
Component Type
PCB Header
Material - Resin
Polyester
Flammability
94V-0
Lock to Mating Part
Yes
Breakaway
Yes
Max-Duration
5
Shrouded
Partial
Glow-Wire Capable
No
Product Name
KK 396
Polarized to PCB
No
Max-Temp
235
Material - Plating Mating
Gold
Pitch - Mating Interface
3.96mm
PCB Locator
No
Circuits (Loaded)
3
Orientation
Vertical
Material - Metal
Brass
PCB Retention
None
Stackable
No

Description

Board Connector, 3 Contact(S), 1 Row(S), Male, Straight, 0.156 Inch Pitch, Solder Terminal, Locking, Black Insulator, Receptacle
