  11. Board Connector, 32 Contact(S), 2 Row(S), Female, Straight, 0.1 Inch Pitch, Solder Terminal, Black
Molex Board Connector, 32 Contact(S), 2 Row(S), Female, Straight, 0.1 Inch Pitch, Solder Terminal, Black 15445832 - main

Board Connector, 32 Contact(S), 2 Row(S), Female, Straight, 0.1 Inch Pitch, Solder Terminal, Black

  • Mfr # 15445832

  • Zoro # G105892033

product price: $8.39
/ea
Sold in multiples of 8 for $67.12

Key Features

Max. Voltage
250V
Max. Temp.
260°C
Application
Board-to-Board, Signal
Series
71850
Standards
CSA Certified; UL E29179
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
15445832
Zoro #
G105892033
UPC #
800753782112
Country of Origin
United States

Dimensions

Contact Plating Thickness
0.381 µm
PC Tail Length
3.05mm
PCB Thickness - Recommended
1.57mm

Details

Max. Voltage
250V
Max. Temp.
260°C
Application
Board-to-Board, Signal
Series
71850
Standards
CSA Certified; UL E29179
Material
High Temperature Thermoplastic
Color
Black
Sub-Category
PCB Receptacles
Terminal Type
Through Hole
Hole Center to Center
2.54 mm
Current Rating
2.5 A
Number of Contacts
32
Contact Finish
Gold Plated
Flammability Rating
UL 94V-0
Number of Rows
2
Terminal Finish
Tin Plated
PCB Locator
No
Flammability
94V-0
Current - Maximum per Contact
2.5A
Material - Resin
High Temperature Thermoplastic
Material - Plating Mating
Gold
Plating min - Mating
0.381µm
Temperature Range - Operating
-40° to +105°C
Material - Metal
Phosphor Bronze
Component Type
PCB Receptacle
Material - Plating Termination
Tin
Glow-Wire Capable
No
PCB Retention
None
Circuits (Loaded)
32
Orientation
Vertical
CSA
LR19980
UL
E29179
Pitch - Mating Interface
2.54mm
Durability (mating cycles max)
50
Product Name
C-Grid
Max-Temp
260
Polarized to PCB
No

Description

Board Connector, 32 Contact(S), 2 Row(S), Female, Straight, 0.1 Inch Pitch, Solder Terminal, Black Insulator, Receptacle
