Board Connector, 34 Contact(S), 2 Row(S), Male Or Female, 0.1 Inch Pitch, Crimp Terminal, Black
Mfr # 22552343
Zoro # G505891919
product price:Â
$
1.89
/ea
Sold in multiples of 50 for $94.50
Key Features
Max. Temp.
105°C
Application
Signal, Wire-to-Board
Series
70450
Standards
CSA Certified; UL E29179
Material
Polyester
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- 22552343
- Zoro #
- G505891919
- UPC #
- -
- Country of Origin
- United States
- Max. Temp.
- 105°C
- Application
- Signal, Wire-to-Board
- Series
- 70450
- Standards
- CSA Certified; UL E29179
- Material
- Polyester
- Hole Center to Center
- 2.54 mm
- Connector Type
- Receptacle
- Color
- Black
- Flammability Rating
- UL 94V-0
- Number of Rows
- 2
- Number of Contacts
- 34
- Pitch - Mating Interface
- 2.54mm
- Product Name
- SL
- Glow-Wire Capable
- No
- Flammability
- 94V-0
- UL
- E29179
- Breakaway
- No
- Temperature Range - Operating
- -40° to +105°C
- Material - Resin
- Polyester
- CSA
- LR19980
- Stackable
- Yes
- Circuits (maximum)
- 34
Description
Board Connector, 34 Contact(S), 2 Row(S), Male Or Female, 0.1 Inch Pitch, Crimp Terminal, Black Insulator
