Board Connector, 38 Contact(S), 2 Row(S), 0.079 Inch Pitch, Locking, Natural Insulator, Receptacle
Mfr # 5016463800
Zoro # G105892804
product price:Â
$
1.15
/ea
Sold in multiples of 85 for $97.75
Key Features
Max. Temp.
105°C
Application
Signal, Wire-to-Board
Series
501646
Standards
CSA Certified; UL E29179
Material
Nylon
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 5016463800
- Zoro #
- G105892804
- UPC #
- -
- Country of Origin
- Japan
Details
- Max. Temp.
- 105°C
- Application
- Signal, Wire-to-Board
- Series
- 501646
- Standards
- CSA Certified; UL E29179
- Material
- Nylon
- Connector Type
- Receptacle
- Hole Center to Center
- 2 mm
- Color
- Natural
- Flammability Rating
- UL 94V-0
- Number of Rows
- 2
- Number of Contacts
- 38
- Product Name
- iGrid
- Lock to Mating Part
- Yes
- Keying to Mating Part
- None
- UL
- E29179
- Glow-Wire Capable
- No
- Polarized to Mating Part
- Yes
- Flammability
- 94V-0
- Pitch - Mating Interface
- 2.00mm
- Temperature Range - Operating
- -40° to +105°C
- Circuits (maximum)
- 38
- Stackable
- No
- CSA
- LR19980
- Material - Resin
- Nylon
