  11. Board Connector, 42 Contact(S), 2 Row(S), Male, Straight, 0.079 Inch Pitch, Surface Mount Terminal,
Molex Board Connector, 42 Contact(S), 2 Row(S), Male, Straight, 0.079 Inch Pitch, Surface Mount Terminal, 878324221 - main

Board Connector, 42 Contact(S), 2 Row(S), Male, Straight, 0.079 Inch Pitch, Surface Mount Terminal,

  • Mfr # 878324221

  • Zoro # G105891241

product price: $5.29
/ea
Sold in multiples of 16 for $84.64

Key Features

Max. Voltage
125V
Max. Temp.
260°C
Application
Signal, Wire-to-Board
Series
87832
Standards
CSA Certified; UL E29179
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
878324221
Zoro #
G105891241
UPC #
-
Country of Origin
Malaysia

Dimensions

Contact Plating Thickness
0.762 µm

Details

Max. Voltage
125V
Max. Temp.
260°C
Application
Signal, Wire-to-Board
Series
87832
Standards
CSA Certified; UL E29179
Material
Nylon
Terminal Type
Surface Mount
Color
Black
Features
Surface Mount Compatible
Hole Center to Center
2 mm
Number of Contacts
42
Flammability Rating
UL 94V-0
Number of Rows
2
Current Rating
2 A
Contact Finish
Gold Plated
Terminal Finish
Tin Plated
Material - Resin
Nylon
Max-Duration
10
Polarized to PCB
No
Breakaway
No
Temperature Range - Operating
-55° to +105°C
Max-Cycle
3
Material - Plating Termination
Tin
Current - Maximum per Contact
2.0A
Guide to Mating Part
No
Orientation
Vertical
PCB Retention
None
Material - Plating Mating
Gold
Material - Metal
Phosphor Bronze
Pitch - Mating Interface
2.00mm
UL
E29179
Lock to Mating Part
Yes
Component Type
PCB Header
Durability (mating cycles max)
100
Product Name
Milli-Grid
First Mate / Last Break
No
Flammability
94V-0
CSA
LR19980
Keying to Mating Part
Yes
Stackable
No
Max-Temp
260
Shrouded
Fully
Circuits (Loaded)
42
PCB Locator
Yes
Glow-Wire Capable
No
Plating min - Mating
0.762µm

Description

Board Connector, 42 Contact(S), 2 Row(S), Male, Straight, 0.079 Inch Pitch, Surface Mount Terminal, Locking, Black Insulator, Receptacle
