  11. Board Connector, 50 Contact(S), 2 Row(S), Female, Right Angle, 0.1 Inch Pitch, Solder Terminal,
Molex Board Connector, 50 Contact(S), 2 Row(S), Female, Right Angle, 0.1 Inch Pitch, Solder Terminal, 719730225 - main

Board Connector, 50 Contact(S), 2 Row(S), Female, Right Angle, 0.1 Inch Pitch, Solder Terminal,

  • Mfr # 719730225

  • Zoro # G205891820

product price: $9.99
/ea
Sold in multiples of 2688 for $26,853.12

Key Features

Max. Voltage
250V
Max. Temp.
260°C
Application
Board-to-Board, Signal
Series
71973
Standards
CSA Certified; UL E29179
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
719730225
Zoro #
G205891820
UPC #
800755017816
Country of Origin
Indonesia

Dimensions

Contact Plating Thickness
0.381 µm
PC Tail Length
3.05mm
PCB Thickness - Recommended
3.05mm

Details

Max. Voltage
250V
Max. Temp.
260°C
Application
Board-to-Board, Signal
Series
71973
Standards
CSA Certified; UL E29179
Material
High Temperature Thermoplastic
Sub-Category
PCB Receptacles
Terminal Type
Through Hole
Hole Center to Center
2.54 mm
Color
Black
Number of Contacts
50
Number of Rows
2
Current Rating
2 A
Contact Finish
Gold Plated
Flammability Rating
UL 94V-0
Terminal Finish
Tin Plated
Pitch - Mating Interface
2.54mm
Max-Duration
10
Max-Cycle
3
Material - Plating Termination
Tin
Durability (mating cycles max)
50
Temperature Range - Operating
-40° to +105°C
UL
E29179
Material - Resin
High Temperature Thermoplastic
Current - Maximum per Contact
2.0A
Polarized to PCB
No
PCB Locator
No
PCB Retention
None
Orientation
Right Angle
Flammability
94V-0
Circuits (Loaded)
50
CSA
LR19980
Max-Temp
260
Component Type
PCB Receptacle
Material - Plating Mating
Gold
Glow-Wire Capable
No
Product Name
C-Grid
Material - Metal
Phosphor Bronze
Plating min - Mating
0.381µm

Description

Board Connector, 50 Contact(S), 2 Row(S), Female, Right Angle, 0.1 Inch Pitch, Solder Terminal, Locking, Black Insulator, Receptacle
