  11. Board Connector, 7 Contact(S), 1 Row(S), Female, Straight, 0.1 Inch Pitch, Solder Terminal,
Molex Board Connector, 7 Contact(S), 1 Row(S), Female, Straight, 0.1 Inch Pitch, Solder Terminal, 448120007 - main

Board Connector, 7 Contact(S), 1 Row(S), Female, Straight, 0.1 Inch Pitch, Solder Terminal,

  • Mfr # 448120007

  • Zoro # G205892452

product price: $2.65
/ea
Sold in multiples of 30 for $79.50

Key Features

Max. Voltage
500V
Max. Temp.
250°C
Application
Board-to-Board, Power
Series
44812
Standards
CSA Certified; UL E29179
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
448120007
Zoro #
G205892452
UPC #
-
Country of Origin
United States

Dimensions

Contact Plating Thickness
5.08 µm
PCB Thickness - Recommended
1.60mm

Details

Max. Voltage
500V
Max. Temp.
250°C
Application
Board-to-Board, Power
Series
44812
Standards
CSA Certified; UL E29179
Color
Black
Features
Surface Mount Compatible
Material
High Temperature Thermoplastic
Hole Center to Center
2.54 mm
Terminal Type
Through Hole
Flammability Rating
UL 94V-0
Contact Finish
Tin Plated
Terminal Finish
Tin Plated
Number of Rows
1
Number of Contacts
7
Current Rating
5 A
Material - Plating Mating
Tin
Component Type
PCB Receptacle
Orientation
Vertical
Current - Maximum per Contact
5.0A
UL
E29179
Flammability
94V-0
Max-Duration
5
Product Name
KK 254
Plating min - Mating
5.080µm
CSA
LR19980
PCB Retention
None
Temperature Range - Operating
See Product Specification
Material - Metal
High Performance Alloy (HPA)
Polarized to PCB
No
Circuits (Loaded)
7
PCB Locator
No
Glow-Wire Capable
No
Durability (mating cycles max)
25
Pitch - Mating Interface
2.54mm
Max-Temp
250
Material - Plating Termination
Tin
Material - Resin
High Temperature Thermoplastic

Description

Board Connector, 7 Contact(S), 1 Row(S), Female, Straight, 0.1 Inch Pitch, Solder Terminal, Locking, Black Insulator, Plug
