  9. Board Stacking Connector, 5 Contact(S), 1 Row(S), Male, Straight, 0.1 Inch Pitch, Solder Terminal,
Molex Board Stacking Connector, 5 Contact(S), 1 Row(S), Male, Straight, 0.1 Inch Pitch, Solder Terminal, 879370502 - main

Board Stacking Connector, 5 Contact(S), 1 Row(S), Male, Straight, 0.1 Inch Pitch, Solder Terminal,

  • Mfr # 879370502

  • Zoro # G505911587

product price: $0.33
/ea
Sold in multiples of 350 for $115.50

Key Features

Color
Black
Number of Rows
1
Series
87937
Max. Voltage
250V
Application
Board-to-Board, Signal, Wire-to-Board
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
879370502
Zoro #
G505911587
UPC #
-
Country of Origin
Indonesia

Dimensions

Contact Plating Thickness
2.54 µm
PC Tail Length
3.76mm
PCB Thickness - Recommended
1.60mm
Mated Height
3.78mm

Details

Color
Black
Number of Rows
1
Series
87937
Max. Voltage
250V
Application
Board-to-Board, Signal, Wire-to-Board
Features
Breakaway; Surface Mount Compatible
Hole Center to Center
2.54 mm
Material
Nylon
Standards
CSA Certified; UL E29179
Max. Temp.
265°C
Terminal Type
Through Hole
Terminal Finish
Nickel Plated
Number of Contacts
5
Current Rating
3 A
Flammability Rating
UL 94V-0
Contact Finish
Tin Plated
Current - Maximum per Contact
3.0A
Stackable
No
Guide to Mating Part
No
Circuits (Loaded)
5
Polarized to Mating Part
No
Material - Plating Termination
Nickel
Material - Plating Mating
Tin
Material - Resin
Nylon
Orientation
Vertical
Max-Duration
14
Pitch - Mating Interface
2.54mm
Keying to Mating Part
None
Breakaway
Yes
Glow-Wire Capable
No
Max-Temp
265
Component Type
PCB Header
Temperature Range - Operating
-55° to +105°C
CSA
LR19880
Product Name
KK 254
Lock to Mating Part
None
PCB Locator
No
Plating min - Mating
2.540µm
Material - Metal
Copper Alloy
Polarized to PCB
No
Shrouded
No
First Mate / Last Break
No
PCB Retention
None
Flammability
94V-0
UL
E29179

Description

Board Stacking Connector, 5 Contact(S), 1 Row(S), Male, Straight, 0.1 Inch Pitch, Solder Terminal, Locking, Black Insulator, Receptacle
