Shop MOLEX

CGrid Hrd SRDW THole 2.54SnLF 4Ckt

  • Mfr # 87937-0406

  • Zoro # G4051379

product price:  $0.32
/ea
Sold in multiples of 382 for $122.24

Key Features

Max. Cycles at Max. Process Temperature
1
Flammability
94V-0
Circuits (maximum)
4
Circuits (Loaded)
4
Process Temperature max. C
265
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
87937-0406
Zoro #
G4051379
UPC #
-
Country of Origin
Indonesia

Dimensions

Mated Height
3.78mm
PCB Thickness - Recommended
1.60mm
PC Tail Length
3.76mm

Details

Max. Cycles at Max. Process Temperature
1
Flammability
94V-0
Circuits (maximum)
4
Circuits (Loaded)
4
Process Temperature max. C
265
Material - Resin
Nylon
Material - Plating Mating
Tin
CSA
LR19880
Breakaway
Yes
Pitch - Mating Interface
2.54mm
Plating min - Termination
1.270µm
UL
E29179
Termination Interface: Style
Through Hole
Plating min - Mating
2.540µm
Color - Resin
Black
Current - Maximum per Contact
3.0A
Duration at Max. Process Temperature (seconds)
14
Number of Rows
1
Pitch - Termination Interface
2.54mm
Voltage - Maximum
250V
Orientation
Vertical
Temperature Range - Operating
-55° to +105°C
Material - Plating Termination
Nickel
Surface Mount Compatible (SMC)
Yes
Material - Metal
Copper Alloy
