  11. Dip Connector, 3 Contact(S), 2 Row(S), Female, Right Angle, 0.059 Inch Pitch, Solder Terminal,
Molex Dip Connector, 3 Contact(S), 2 Row(S), Female, Right Angle, 0.059 Inch Pitch, Solder Terminal, 5031750301 - main

Dip Connector, 3 Contact(S), 2 Row(S), Female, Right Angle, 0.059 Inch Pitch, Solder Terminal,

  • Mfr # 5031750301

  • Zoro # G905980718

product price: $0.12
/ea
Sold in multiples of 910 for $109.20

Key Features

Max. Temp.
105°C
Max. Voltage
100V
Application
Signal, Wire-to-Board
Series
503175
Terminal Type
Through Hole
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
5031750301
Zoro #
G905980718
UPC #
-
Country of Origin
Japan

Dimensions

PCB Thickness - Recommended
1.60mm, 2.40mm

Details

Max. Temp.
105°C
Max. Voltage
100V
Application
Signal, Wire-to-Board
Series
503175
Terminal Type
Through Hole
Color
Black
Material
Copper Alloy
Hole Center to Center
1.5 mm
Number of Rows
1
Number of Contacts
3
Contact Finish
Tin Plated
Current Rating
2 A
Terminal Finish
Tin Plated
Orientation
Right Angle
Glow-Wire Capable
No
Polarized to PCB
Yes
Stackable
No
Keying to Mating Part
None
Lock to Mating Part
Yes
PCB Retention
Yes
Product Name
CLIK-Mate
Pitch - Mating Interface
1.50mm
Durability (mating cycles max)
30
Material - Plating Mating
Tin
Current - Maximum per Contact
2.0A
Temperature Range - Operating
-40° to +105°C
Material - Plating Termination
Tin
Guide to Mating Part
Yes
Circuits (Loaded)
3
PCB Locator
Yes
Component Type
PCB Receptacle
Polarized to Mating Part
Yes

Description

Dip Connector, 3 Contact(S), 2 Row(S), Female, Right Angle, 0.059 Inch Pitch, Solder Terminal, Locking, Black Insulator, Receptacle
