  9. Headers & Wire Housings 10Ckt 2.5Mm L/P Wafr Asy 526710Ax
Molex Headers & Wire Housings 10Ckt 2.5Mm L/P Wafr Asy 526710Ax 99990994 - main

Headers & Wire Housings 10Ckt 2.5Mm L/P Wafr Asy 526710Ax

  • Mfr # 99990994

  • Zoro # G505911488

product price: $0.32
/ea
Sold in multiples of 300 for $96.00

Key Features

Color
Natural
Number of Rows
1
Series
5267
Max. Voltage
250V
Application
Signal, Wire-to-Board
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
99990994
Zoro #
G505911488
UPC #
-
Country of Origin
Malaysia

Dimensions

Contact Plating Thickness
4.064 µm
PC Tail Length
3.50mm
PCB Thickness - Recommended
1.60mm

Details

Color
Natural
Number of Rows
1
Series
5267
Max. Voltage
250V
Application
Signal, Wire-to-Board
Hole Center to Center
2.5 mm
Material
Nylon
Standards
CSA Certified; UL E29179
Max. Temp.
105°C
Terminal Type
Through Hole
Terminal Finish
Tin Plated
Flammability Rating
UL 94V-0
Number of Contacts
10
Current Rating
3 A
Contact Finish
Tin Plated
CSA
LR19980
PCB Retention
Yes
Lock to Mating Part
Yes
Polarized to Mating Part
Yes
Flammability
94V-0
Orientation
Vertical
Glow-Wire Capable
No
Product Name
Mini-SPOX
PCB Locator
No
Polarized to PCB
No
UL
E29179
Circuits (Loaded)
10
First Mate / Last Break
No
Guide to Mating Part
No
Temperature Range - Operating
-55° to +105°C
Keying to Mating Part
None
Component Type
PCB Header
Plating min - Mating
4.064µm
Breakaway
No
Material - Plating Mating
Tin
Material - Plating Termination
Tin
Shrouded
Fully
Material - Resin
Nylon
Stackable
No
Durability (mating cycles max)
30
Pitch - Mating Interface
2.50mm
Current - Maximum per Contact
3.0A
