  9. Headers & Wire Housings C-Grid Pcb Conn Dr V Conn Dr Vt Au-E 8Ckt
Molex Headers & Wire Housings C-Grid Pcb Conn Dr V Conn Dr Vt Au-E 8Ckt 901512208 - main

Headers & Wire Housings C-Grid Pcb Conn Dr V Conn Dr Vt Au-E 8Ckt

  • Mfr # 901512208

  • Zoro # G105911475

product price: $5.15
/ea
Sold in multiples of 13 for $66.95

Key Features

Number of Rows
2
Series
90151
Application
Board-to-Board, Signal
UL
E29179
Pitch - Mating Interface
2.54mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
901512208
Zoro #
G105911475
UPC #
-
Country of Origin
Indonesia

Dimensions

PCB Thickness - Recommended
0.80mm, 1.70mm
PC Tail Length
2.90mm

Details

Number of Rows
2
Series
90151
Application
Board-to-Board, Signal
UL
E29179
Pitch - Mating Interface
2.54mm
Color - Resin
Black
Keying to Mating Part
None
Current - Maximum per Contact
3.0A
PCB Retention
None
Circuits (Loaded)
8
Termination Interface Style
Through Hole
Lock to Mating Part
No
Stackable
Yes
Polarized to PCB
No
Product Name
C-Grid
Component Type
PCB Receptacle
Material - Plating Mating
Gold
Voltage - Maximum
350V
Flammability
94HB
Glow-Wire Capable
No
Temperature Range - Operating
-55° to +125°C
Material - Metal
Phosphor Bronze
Material - Plating Termination
Tin
Plating min - Mating
0.381µm
Material - Resin
Polyester
Durability (mating cycles max)
100
Orientation
Vertical
PCB Locator
No
Guide to Mating Part
No
Grounding to PCB
No
