  9. Headers & Wire Housings C-Grid Pcb Conn Dr Vt Tn-A 4Ckt
Molex Headers & Wire Housings C-Grid Pcb Conn Dr Vt Tn-A 4Ckt 901512104 - main

Headers & Wire Housings C-Grid Pcb Conn Dr Vt Tn-A 4Ckt

  • Mfr # 901512104

  • Zoro # G405911618

product price: $1.25
/ea
Sold in multiples of 4200 for $5,250.00

Key Features

Color
Black
Number of Rows
2
Series
90151
Max. Voltage
350V
Application
Board-to-Board, Signal
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
901512104
Zoro #
G405911618
UPC #
800753672451
Country of Origin
Singapore

Dimensions

Contact Plating Thickness
1.016 µm
PCB Thickness - Recommended
0.80mm, 1.70mm
PC Tail Length
2.90mm

Details

Color
Black
Number of Rows
2
Series
90151
Max. Voltage
350V
Application
Board-to-Board, Signal
Sub-Category
PCB Receptacles
Hole Center to Center
2.54 mm
Material
Polyester
Terminal Type
Through Hole
Max. Temp.
230°C
Standards
UL E29179
Number of Contacts
4
Terminal Finish
Tin Plated
Flammability Rating
UL 94HB
Contact Finish
Tin Plated
Current Rating
3 A
Orientation
Vertical
Glow-Wire Capable
No
Temperature Range - Operating
-55° to +125°C
Keying to Mating Part
None
Polarized to PCB
No
Current - Maximum per Contact
3.0A
Pitch - Mating Interface
2.54mm
Flammability
94HB
Durability (mating cycles max)
30
Guide to Mating Part
No
PCB Locator
No
Stackable
Yes
Product Name
C-Grid
Max-Cycle
1
Max-Duration
5
Grounding to PCB
No
Material - Metal
Phosphor Bronze
Material - Plating Termination
Tin
Lock to Mating Part
No
UL
E29179
Plating min - Mating
1.016µm
PCB Retention
None
Material - Plating Mating
Tin
Material - Resin
Polyester
Max-Temp
230
Component Type
PCB Receptacle
Circuits (Loaded)
4
