  9. Headers & Wire Housings Kk 100 Pcb Assy Top Assy Top 20 Ckt Tin
Molex Headers & Wire Housings Kk 100 Pcb Assy Top Assy Top 20 Ckt Tin 38001440 - main

Headers & Wire Housings Kk 100 Pcb Assy Top Assy Top 20 Ckt Tin

  • Mfr # 38001440

  • Zoro # G405911083

product price: $3.45
/ea
Sold in multiples of 972 for $3,353.40

Key Features

Number of Rows
1
Material
Nylon
Color
Natural
Standards
CSA Certified; UL E29179
Series
4455
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
38001440
Zoro #
G405911083
UPC #
-
Country of Origin
Mexico

Dimensions

Contact Plating Thickness
1.016 µm
PC Tail Length
3.30mm
PCB Thickness - Recommended
1.60mm

Details

Number of Rows
1
Material
Nylon
Color
Natural
Standards
CSA Certified; UL E29179
Series
4455
Application
Board-to-Board, Signal
Max. Voltage
500V
Terminal Finish
Tin Plated
Hole Center to Center
2.54 mm
Terminal Type
Through Hole
Current Rating
2.5 A
Flammability Rating
UL 94V-0
Max. Temp.
235°C
Contact Finish
Tin Plated
Number of Contacts
20
Grounding to PCB
No
Material - Metal
Phosphor Bronze
Product Name
KK 254
Material - Plating Termination
Tin
Current - Maximum per Contact
2.5A
Temperature Range - Operating
See Product Specification
Keying to Mating Part
None
PCB Locator
No
Color - Resin
Natural (White)
Max-Duration
5
Orientation
Vertical
Polarized to PCB
No
Component Type
PCB Receptacle
Max-Temp
235
Lock to Mating Part
No
Flammability
94V-0
Guide to Mating Part
No
UL
E29179
CSA
LR19980
Circuits (Loaded)
20
Glow-Wire Capable
No
Plating min - Mating
1.016µm
Pitch - Mating Interface
2.54mm
Material - Plating Mating
Tin
PCB Retention
None
Material - Resin
Nylon
