Molex Mf+ Hcs Vert Hdr Dr 24Ckt V-0 Peg Tin 460152403 - main

Mf+ Hcs Vert Hdr Dr 24Ckt V-0 Peg Tin

  • Mfr # 460152403

  • Zoro # G405910574

product price:  $3.85
/ea
Sold in multiples of 21 for $80.85

Key Features

Number of Rows
2
Max. Voltage
600V
Material
Nylon
Color
Natural
Terminal Type
Through Hole
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
460152403
Zoro #
G405910574
UPC #
-
Country of Origin
Mexico

Dimensions

Contact Plating Thickness
2.54 µm
PC Tail Length
1.80mm
PCB Thickness - Recommended
1.78mm

Details

Number of Rows
2
Max. Voltage
600V
Material
Nylon
Color
Natural
Terminal Type
Through Hole
Hole Center to Center
4.2 mm
Application
Power, Wire-to-Board
Max. Temp.
240°C
Standards
CSA Certified; UL E29179
Series
46015
Terminal Finish
Tin Plated
Contact Finish
Tin Plated
Current Rating
13 A
Number of Contacts
24
Flammability Rating
UL 94V-0
Circuits (Loaded)
24
Shrouded
Fully
Flammability
94V-0
Component Type
PCB Header
Product Name
Mini-Fit Plus
UL
E29179
Guide to Mating Part
No
Polarized to PCB
Yes
Material - Plating Mating
Tin
Current - Maximum per Contact
13.0A
Stackable
No
Material - Metal
Copper Alloy
Max-Temp
240
Polarized to Mating Part
Yes
PCB Retention
Yes
Max-Duration
5
Orientation
Vertical
Temperature Range - Operating
-40° to +105°C
Plating min - Mating
2.540µm
Glow-Wire Capable
No
Keying to Mating Part
None
Pitch - Mating Interface
4.20mm
Durability (mating cycles max)
75
Material - Plating Termination
Tin
First Mate / Last Break
No
Lock to Mating Part
Yes
CSA
LR19980
PCB Locator
Yes
Max-Cycle
1
Breakaway
No
Material - Resin
Nylon
