  9. Mgrid Shrd Hdr Ra Th /Opeg 2.5Snlf 20Ckt
Molex Mgrid Shrd Hdr Ra Th /Opeg 2.5Snlf 20Ckt 1511193020 - main

Mgrid Shrd Hdr Ra Th /Opeg 2.5Snlf 20Ckt

  • Mfr # 1511193020

  • Zoro # G205910101

product price: $1.35
/ea
Sold in multiples of 85 for $114.75

Key Features

Color
Black
Number of Rows
2
Series
151119
Max. Voltage
125V AC
Application
Board-to-Board, Signal, Wire-to-Board
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
1511193020
Zoro #
G205910101
UPC #
-
Country of Origin
Singapore

Dimensions

Contact Plating Thickness
2 µm
PCB Thickness - Recommended
1.60mm
PC Tail Length
2.60mm

Details

Color
Black
Number of Rows
2
Series
151119
Max. Voltage
125V AC
Application
Board-to-Board, Signal, Wire-to-Board
Max. Temp.
260°C
Terminal Type
Through Hole
Material
Liquid Crystal Polymer
Standards
CSA Certified; UL E29179
Hole Center to Center
2 mm
Features
Glow-Wire Capable; Surface Mount Compatible
Number of Contacts
20
Flammability Rating
UL 94V-0
Contact Finish
Tin Plated
Terminal Finish
Tin Plated
Current Rating
2 A
Material - Plating Termination
Tin
Stackable
No
Breakaway
No
Flammability
94V-0
Polarized to Mating Part
Yes
Max-Duration
10
Orientation
Right Angle
PCB Retention
None
Material - Resin
Liquid Crystal Polymer
Material - Metal
Copper Alloy
Keying to Mating Part
None
CSA
LR19980
Component Type
PCB Header
Guide to Mating Part
No
Product Name
Milli-Grid
First Mate / Last Break
No
Shrouded
Yes
Plating min - Mating
2.000µm
Max-Cycle
1
PCB Locator
No
Current - Maximum per Contact
2.0A
Material - Plating Mating
Tin
Glow-Wire Capable
Yes
Pitch - Mating Interface
2.00mm
Circuits (Loaded)
20
Lock to Mating Part
Yes
Max-Temp
260
UL
E29179
Polarized to PCB
Yes
Temperature Range - Operating
-55° to +105°C
