Shop MOLEX

Micro-Fit Plus Sr Ra Hdr Assy 30Au 1X6

  • Mfr # 2157603006

  • Zoro # G005910165

product price:
$
2.95
/ea
Sold in multiples of 30 for $88.50

Key Features

Number of Rows
1
Series
215760
Application
Power, Wire-to-Board
PCB Retention
Yes
Temperature Range - Operating
-40° to +105°C
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
2157603006
Zoro #
G005910165
UPC #
-
Country of Origin
China

Dimensions

PCB Thickness - Recommended
1.57mm
PC Tail Length
3.17mm

Details

Number of Rows
1
Series
215760
Application
Power, Wire-to-Board
PCB Retention
Yes
Temperature Range - Operating
-40° to +105°C
First Mate / Last Break
No
Flammability
94V-0
Glow-Wire Capable
Yes
Shrouded
Yes
Material - Metal
High Copper Alloy
Plating min - Mating
0.762µm
Product Name
Micro-Fit+
Material - Resin
Liquid Crystal Polymer
Breakaway
No
Durability (mating cycles max)
200
Orientation
Right Angle
CSA
LR19980
Material - Plating Mating
Gold
Polarized to Mating Part
Yes
UL
E29179
Pitch - Mating Interface
3.00mm
Keying to Mating Part
Yes
Current - Maximum per Contact
12.5A
Component Type
PCB Header
Polarized to PCB
Yes
Material - Plating Termination
Matte Tin
Voltage - Maximum
600V AC (RMS)/DC
Color - Resin
Black
Lock to Mating Part
Yes
Termination Interface Style
Through Hole
Circuits (Loaded)
6
