  9. Micro-Fit Plus Sr Ra Hdr Assy 30Au 1X7
This item is Discontinued.
Molex Micro-Fit Plus Sr Ra Hdr Assy 30Au 1X7 2157603007

Micro-Fit Plus Sr Ra Hdr Assy 30Au 1X7 (Discontinued)

  • Mfr # 2157603007
  • Zoro # G405910116
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
2157603007
Zoro #
G405910116
UPC #
-
Country of Origin
China

Dimensions

PC Tail Length
3.17mm
PCB Thickness - Recommended
1.57mm

Details

Number of Rows
1
Series
215760
Application
Power, Wire-to-Board
Material - Metal
High Copper Alloy
CSA
LR19980
Color - Resin
Black
UL
E29179
Lock to Mating Part
Yes
Pitch - Mating Interface
3.00mm
Durability (mating cycles max)
200
Product Name
Micro-Fit+
Keying to Mating Part
Yes
Material - Plating Termination
Matte Tin
Polarized to Mating Part
Yes
Component Type
PCB Header
Material - Plating Mating
Gold
Voltage - Maximum
600V AC (RMS)/DC
Breakaway
No
Glow-Wire Capable
Yes
Flammability
94V-0
Plating min - Mating
0.762µm
Current - Maximum per Contact
12.5A
Temperature Range - Operating
-40° to +105°C
Material - Resin
Liquid Crystal Polymer
Orientation
Right Angle
Polarized to PCB
Yes
PCB Retention
Yes
Termination Interface Style
Through Hole
Circuits (Loaded)
7
First Mate / Last Break
No
Shrouded
Yes
