  9. Micro-Fit Plus Sr Ra Hdr Assy Tin 1X6
This item is Discontinued.
Molex Micro-Fit Plus Sr Ra Hdr Assy Tin 1X6 2157601006

Micro-Fit Plus Sr Ra Hdr Assy Tin 1X6 (Discontinued)

  • Mfr # 2157601006
  • Zoro # G505909867
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
2157601006
Zoro #
G505909867
UPC #
-
Country of Origin
China

Dimensions

PC Tail Length
3.17mm
PCB Thickness - Recommended
1.57mm

Details

Number of Rows
1
Series
215760
Application
Power, Wire-to-Board
Lock to Mating Part
Yes
Pitch - Mating Interface
3.00mm
Current - Maximum per Contact
13.0A
Glow-Wire Capable
Yes
Voltage - Maximum
600V AC (RMS)/DC
Shrouded
Yes
Temperature Range - Operating
-40° to +105°C
CSA
LR19980
Circuits (Loaded)
6
Durability (mating cycles max)
25
UL
E29179
Material - Plating Termination
Matte Tin
PCB Retention
Yes
Material - Resin
Liquid Crystal Polymer
Material - Plating Mating
Matte Tin
Component Type
PCB Header
Color - Resin
Black
Polarized to Mating Part
Yes
Product Name
Micro-Fit+
Breakaway
No
Orientation
Right Angle
Flammability
94V-0
Keying to Mating Part
Yes
Material - Metal
High Copper Alloy
Termination Interface Style
Through Hole
Polarized to PCB
Yes
First Mate / Last Break
No
