  9. Micro-Fit Plus Sr Vt Hdr Assy 15Au 1X6
Molex Micro-Fit Plus Sr Vt Hdr Assy 15Au 1X6 2165712006 - main

Micro-Fit Plus Sr Vt Hdr Assy 15Au 1X6

  • Mfr # 2165712006

  • Zoro # G705910199

product price: $1.95
/ea
Sold in multiples of 45 for $87.75

Key Features

Number of Rows
1
Series
216571
Application
Power, Wire-to-Board
Component Type
PCB Header
Plating min - Mating
0.381µm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
2165712006
Zoro #
G705910199
UPC #
-
Country of Origin
China

Dimensions

PC Tail Length
3.18mm
PCB Thickness - Recommended
1.57mm

Details

Number of Rows
1
Series
216571
Application
Power, Wire-to-Board
Component Type
PCB Header
Plating min - Mating
0.381µm
Lock to Mating Part
Yes
Current - Maximum per Contact
12.5A
Polarized to PCB
Yes
Durability (mating cycles max)
200
Orientation
Vertical
Glow-Wire Capable
Yes
Product Name
Micro-Fit+
Material - Plating Termination
Matte Tin
Flammability
94V-0
First Mate / Last Break
No
Circuits (Loaded)
6
Max-Cycle
3
Max-Duration
30
Max-Temp
260
CSA
LR19980
Keying to Mating Part
Yes
Breakaway
No
Pitch - Mating Interface
3.00mm
Voltage - Maximum
600V AC (RMS)/DC
Material - Metal
High Copper Alloy
Temperature Range - Operating
-40° to +105°C
Material - Resin
Liquid Crystal Polymer
UL
E29179
Shrouded
Yes
Termination Interface Style
Through Hole
Material - Plating Mating
Gold
PCB Retention
Yes
Polarized to Mating Part
Yes
Color - Resin
Black
