Contact our U.S. based teamSpecifications
Product Information
MFR #
43045-1028
Zoro #
G7769970
UPC #
-
Country of Origin
Unknown
Dimensions
Contact Plating Thickness
0.381 µm
Details
Color
Black
Max. Voltage
600V
Maximum Voltage
600 V
Standards
CSA Certified; UL E29179
Maximum Operating Temperature
260 Degrees C
UL 94 Flammability Rating
V-0
Material
High Temperature Thermoplastic
Max. Temp.
260°C
Terminal Type
Through Hole
Features
Glow-Wire Capable; Surface Mount Compatible
Hole Center to Center
3 mm
Current Rating
8.5 A
Contact Finish
Gold Plated
Number of Contacts
10
Number of Rows
2
Flammability Rating
UL 94V-0
Terminal Finish
Tin Plated
