Pluggable Terminal Blocks 3.5Mm Euro Plug Ra B Plug Ra Blk Me 8Ckt
Mfr # 395040008
Zoro # G405798202
product price: $2.19
/eaSold in multiples of 39 for $85.41
Key Features
Series
39504
Type
Euro Block
UL
E48521
Entry Angle
Vertical
Current - Maximum per Contact
8.0A
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
395040008
Zoro #
G405798202
UPC #
-
Country of Origin
China
Dimensions
Wire Size AWG
16, 18, 20, 22, 24, 26, 28, 30
Wire Size mm²
0.05-1.31
Details
Series
39504
Type
Euro Block
UL
E48521
Entry Angle
Vertical
Current - Maximum per Contact
8.0A
Polarized to Mating Part
Yes
Pitch - Termination Interface
3.50mm
Number of Rows
1
Lock to Mating Part
Yes
Stackable
No
Temperature Range - Operating
-40° to +105°C
Circuits (Loaded)
8
Voltage - Maximum
300V
Pitch - Mating Interface
3.50mm
Orientation
Horizontal
Panel Mount
No
Product Name
ESE,Eurostyle Pluggable
Component Type
Plug
