Molex Push-In Wire Connector, 18 AWG Max, Black, Nylon Insulation, 300 V AC/DC, 8.5 A 2147572043 - main

Push-In Wire Connector, 18 AWG Max, Black, Nylon Insulation, 300 V AC/DC, 8.5 A

  • Mfr # 2147572043

  • Zoro # G005963581

product price:  $3.89
/ea
Sold in multiples of 20 for $77.80

Key Features

Type
Crimp
Color
Black
Maximum Wire Size
18 AWG
Minimum Wire Size
18 AWG
Insulation Material
Nylon
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
2147572043
Zoro #
G005963581
UPC #
-
Country of Origin
India

Dimensions

Maximum Wire Size
18 AWG
Minimum Wire Size
18 AWG
Length
600 mm
Max. Insulation Dia.
1.85 mm
Contact Plating Thickness
0.762 µm
Cable Length
600.00mm
Wire Insulation Diameter
1.85mm max.

Details

Item
Cable Assembly/Connector
Type
Crimp
Color
Black
Insulation Material
Nylon
Maximum Voltage
300V AC/DC
Current
8.5 A
RoHS Compliant
Yes
Material
Phosphor Bronze
Series
214757
Application
Power, Wire-to-Wire
Hole Center to Center
3 mm
Number of Rows
2
Finish
Gold Plated
Number of Contacts
4
Terminal Finish
Tin Plated
Material - Plating Termination
Tin
Lock to Mating Part
Yes
Single Ended
No
Pitch - Mating Interface
3.00mm
Material - Plating Mating
Gold
Plating min - Mating
0.762µm
Wire/Cable Type
UL 1061
Connector to Connector
Micro-Fit 3.0 Both Ends
Assembly Configuration
Dual Ended Connectors
Overmolded
No
Circuits (Loaded)
4
